Electric Submersible Pump (ESP)

Best efficiency point (BEP) Flow rate, bbl/d at 60 Hz [m3/d at 50 Hz] 1,100 [145.7] Head per stage, ft at 60 Hz [m at 50 Hz] 36.91 [7.82] Required power, hp at 60 Hz [hp at 50 Hz] 0.49 [0.28] Efficiency, % 61.03 General OD, in [mm] 3.87 [98.3] Stage geometry Radial flow Stage metallurgy Ni-Resist®, 5530 alloy Housing metallurgy Carbon steel, Redalloy* premium alloy Shaft diameter, in [mm] 0.68 [17] Shaft material and rating at 60 Hz, hp INCONEL 718, 240 Shaft radial support options ES,† ARZ‡ Pump construction Enhanced compression design, factory-shimmed
