Mesin Sekrap (Shaping Machine)
UNTUK MENGENALKAN DAN MEMBERI KETERAMPILAN MENGERJAKAN BENDA KERJA MENGGUNAKAN MESIN SEKRAP. MAXIMUM DISTANCE FROM RAM BOTTOM TO TABLE SURFACE : 330 MM MAXIMUM TABLE HORIZONTAL TRAVEL : 400 MM MAXIMUM TABLE VERTICAL TRAVEL : 270 MM LEADING SURFACE OF THE PLANER TO BED OUT OF THE MAXIMUM DISTANCE : 550 MM THE MAXIMUM DISPLACEMENT OF THE RAM : 170 MM MAXIMUM TURNING ANGLE OF THE WORKTABLE (NO VICE) : +90° MAXIMUM TURNING ANGLE OF THE WORKTABLE (VICE) : +55° THE TURRET MAXIMUM VERTICAL TRAVEL : 110 MM NUMBER OF RAM STROKES PER MINUTE : 32, 50, 80, 125, TIMES MIN THE RAM BACK AND FORTH A TABLE FEED AMOUNT WHEELED ROUND A TOOTH (VERTICAL) : 0.18 MM WHEELED ROUND A TOOTH (HORIZONTAL) : 0.21 MM WHEELED ROUND 4 TOOTH (VERTICAL) : 0.73 MM WHEELED ROUND 4 TOOTH (HORIZONTAL) : 0.84 MM ELECTRIC : 1.5 KW 1400 R/MIN STANDARD ACCESSORIES : TRANSMISSION BELT, INNER HEXAGON SPANNER, CRANK HANDLE, SPANNER, OIL GUN, FOUNDATION BOLTS, RANDOM TECHNICAL
