Otc Robot Welding Hybrid

- Structure: Vertical
articulated type - Number of Axes: 6 - Max. Payload Capacity: ≥
8 kg - Positional Repeatability:
≤ 0.08 mm - Drive System: AC
Servomotor - Drive Capacity: ≥ 3000 W - Position Feedback:
Absolute Encoder - Working Range:
* Arm: J1 (Rotation) ±170°,
J2 (Lower Arms) -155° to
+90°, J3 (Upper Arms)
170° to +245°
* Wrist: J4 (Swing) ±180°,
J5 (Bending) -50° to
+230°, J6 (Twist) ±360° - Maximum Speed:
* Arm: J1 (Rotation) ≥ 4
rad/s, J2 (Lower Arms) ≥ 4
rad/s, J3 (Upper Arms) ≥
4 rad/s
* Wrist: J4 (Swing) ≥ 7
rad/s, J5 (Bending) ≥ 7
rad/s, J6 (Twist) ≥ 11
rad/s - Wrist Allowable Load:
* Allowable Moment: J4
(Swing) ≥ 17 N.m, J5
(Bending) ≥ 17 N.m, J6
(Twist) ≥ 7 N.m
* Allowable Moment of
Inertia: J4 (Swing) ≥ 0.4
kg.m², J5 (Bending) ≥ 0.4
kg.m², J6 (Twist) ≥ 0.09
kg.m² - Ambient Condition:
Temperature 0 to 45°C,
Humidity 20-80% RH (No
Condensation) - Mass: ≤ 140 kg - Upper Arm Payload
Capacity: ≥ 10 kg - Installation: Floor, wall,
or ceiling - Paint Color: Standard
industrial white
