Sistem Pelatihan Teknologi Dasar Manajemen Air
Peralatan untuk
meningkatkan kompetensi
siswa dalam
mengoperasikan, merawat
dan memperbaiki sistem
penjernihan air, distribusi
air, pengolahan air
limbah. Satu set harus
terdiri dari :
1 set PLC starter kit yang
dilengkapi dengan PC interface.
1 Software package
sebagai media untuk
memberi parameter nilai
ke sistem hardware dan
untuk itu diperlukan juga
koneksi ke PC Interface
1 unit Water supply
tank/ground water (tank
volume: 30 l) with pipe
connection adapter,
submersible pump, float
switch
1 unit Water purification
station, fully assembled,
wired and tested.
Main components 3 l tank,
including an overflow rim,
capacitive proximity
sensor, float switch,
impeller flow sensor,
pressure sensor , 2/2-way
solenoid valve, non-return
valve, electric connection
board, aluminum profile
plate.
1 unit chlorine
measurement package,
equipped with a dropping
funnel, a membrane
covered, amperometric
measuring cell and an
indicator that can be
parameterized. The
measuring cell functions
within an operating range
of 4 to 9 pH.
1 Power supply unit 24 V
DC
