Stability Tester for Asphalt

Untuk menguji kekuatan campuran aspal.
Automatically calculates flow and stability values
Permanent storage capacity up to 10,000 test results
4 analog channels, 2 channels are active for Asphalt
Programmable digital gain adjustment for load-cell, pressure transducers, strain-gauge based sensors, potentiometer sensors, voltage and current transmitters approx. 1/256000 points resolution per channel
10 data per second sample rate for each channel
Ethernet connecting for computer interface
Min. 800×480 resolution TFT-LCD industrial touch screen
3 different unit system selection; kN, Ton and lb
Platen Speed spprox. 6-60 mm/min
Capacity kN approx. 50
Power W approx. 1100
Real time graph display
