Sistem Pelatihan Teknologi Management Air
1 unit Education Kit
untuk Basic process
technology yang berisi
papan kerja
Aluminium, 2 buah
transparent circular
water tanks, Flexible
pipe system DN15,
Rotary pump, normal
intake, 24 Volt/26 W, 2
buttons (NO and NC
contact), 1 control
switch and 1 LED
indicator light (24V) for
front panel installation
with mounting bracket;
1 relay with 3
changeover contacts,
Pressure gauge, Flow
meter, float principle,
Electrical interface
board, pre-wired and
consisting of - I/O
terminal for 8 digital
outputs, 8 inputs with
SysLink plug
connection - Terminal
block for analogue
signals with 15-pin
SUB-D connection - 24
V DC DIN H-rail relay
with operating indicator - Motor controller with
pulse width modulation
for DC motors -
Starting current limiter - 4-wire basic terminal
block - Connection
block 2-pin, 2 x
capacitive sensor with
mounting components
and cable, Ultrasound
proximity switch incl.
plug socket with cable,
Flow sensor with rotor
and opto-electronic
(infrared) evaluation
incl. f/U transducer
and cable
1 set PLC starter kit
yang dilengkapi dengan
PC interface.
1 Software package
sebagai media untuk
memberi parameter nilai ke sistem
hardware dan untuk
itu diperlukan juga
koneksi ke PC Interface
1 unit Alat ukur
konsumsi listrik yang
dapat mengirimkan
data melalui Ethernet
port.
1 unit Water supply
tank/ground water
(tank volume: 30 l) with
pipe connection
adapter, submersible
pump, float switch
1 unit Water
purification station,
fully assembled, wired
and tested.
Main components 3 l
tank, including an
overflow rim, capacitive
proximity sensor, float
switch, impeller flow
sensor, pressure sensor
, 2/2-way solenoid
valve, non-return valve,
electric connection
board, aluminum
profile plate.
1 unit chlorine
measurement package,
equipped with a
dropping funnel, a
membrane-covered,
amperometric
measuring cell and an
indicator that can be
parameterized. The
measuring cell
functions within an
operating range of 4 to
9 pH.
1 Power supply unit 24
V DC
